INSTALLATION &

OPERATION

MANUAL

Contents:

Introduction ...............................................................................2

Unpacking & Pre-Installation .....................................................2

Installation & Mounting ..............................................................2

Magnetic Mounting ....................................................................3

Permanent Mounting .................................................................3

Wiring Instructions...................................................................3-4

Maintenance...............................................................................4

Parts List(Replacement Parts/Exploded Views)......................5-6

Warranty ....................................................................................7

12/24v MODELS

PERMANENT AND MAGNETIC

410AH, 410AMH, 410ASH Series Beacons

Read all instructions and warnings before installing and using.

This manual must be delivered to the end user of this equipment.

IMPORTANT:

INSTALLER:

1 2 3 4 5 6 7
